ADJ Focus Spot 4Z

ADJ Focus Spot 4Z
ADJ Focus Spot 4Z
ADJ Focus Spot 4Z
ADJ Focus Spot 4Z
ADJ Focus Spot 4Z
ADJ Focus Spot 4Z
ADJ Focus Spot 4Z
2-3 Days
ADJ Focus Spot 4Z
ADJ Focus Spot 4Z
ADJ Focus Spot 4Z
ADJ Focus Spot 4Z
ADJ Focus Spot 4Z
ADJ Focus Spot 4Z
ADJ Focus Spot 4Z
ADJ Focus Spot 4Z
$1,099.99

  • Stock: 2-3 Days
  • Model: Focus Spot 4Z

Available Options

Details

The Focus Spot 4Z is powered by a brilliant 200W cool white LED engine and is equipped with motorized focus and zoom (11 ~ 22-degree zoom). Its designed for temporary live events and fixed installations in nightclub, stages or churches. It is professionally fit with one GOBO wheel with 6 rotating/replaceable GOBOS, 8 vibrant colors plus white, and 2 prism wheels (one 5-facet linear and one 6-facet circular).


The Focus Spot 4Z has locking power In/Out connections to daisy chain the power, as well as 3-pin DMX In/Out to transmit a DMX signal from one fixture to the next. There is a USB firmware update port built-in plus advanced control options such as: 16-bit fin pan and tilt, multiple DMX control modes, and 6 different dimming options. The Focus Spot 4Z offers a robust light output in a light weight, compact foot print (18-inch high and one 23 pounds).

Specifications

Specifications

Light Source:

• 200W Cool White LED Engine (50,000 hr.)



Features:

• Motorized Focus

• Motorized Zoom: 11 ~ 22-degrees plus 16-bit Fine Zoom

• 2 Prism FX: Rotating 5-facet Linear & rotating 6-facet Circular

• 0-100% smooth dimming

• Various strobe speeds

• USB firmware update port

• 2 cooling fans



Color Wheel:

• 8 dichroic colors + white



GOBO Wheel:

• 6 aluminum GOBOs + open

• All GOBOs removable & rotatable

• GOBO Shake Effect

• GOBO size: 22.5mm (outer); 19mm (viewable); 0.5-2mm (thickness)



Prism Wheel:

• Prism Wheel 1: Rotatable 5-facet Linear

• Prism Wheel 2: Rotatable 6-facet Circular

• Prism Indexing



Control:

• 3 DMX Channel Modes: 16/18/22 Channels

• Color LCD display with 6-button function menu

• Data In/Out: 3-pin DMX

• Power In/Out: Locking power In/Out connections (Daisy chain 4 units @ 120V; 10 units @ 240V)

• Control Mode: DMX512 or internal programs

• 6 Dimming Curve Modes: Standard, Stage, TV, Architectural, Theatre, Stage 2

• 0-100% smooth dimming

• Various strobe speeds

• USB firmware update port

• With Wired Digital Communication Network



Pan/Tilt:

• Pan: 540 & 630 degrees

• Tilt: 270 degrees



Dimensions & Weight:

• Dimension: 7.15 (L)” x 10.97” (W) x 18” (H) / 181.5 x 278.6 x 457.4mm

• Weight: 23 lbs. / 10 kg.



What’s Included:

• Omega Bracket

• 6 ft/3M Locking power to Edison cable

• Safety Cable


Rating/Approvals:

ETL Approved
